If you're restoring a period property, building a garden office or just replacing a rotting frame, getting the timber right makes all the difference. Timber window frames have been the standard in UK construction for hundreds of years, and they remain the best choice for authenticity, workability and repairability.
This guide covers everything you need to know: the difference between frame types, which timber sections to use, how standard sizes work, and what components make up a complete window.
Types of Timber Window Frames: Casement, Sash and Fixed
Most UK homes have one of two window types, casement or sash, and the timber sections required are different for each. A third type, the fixed frame, is common on sheds and outbuildings.

The three main types of timber window frame.
Casement windows
Casement windows open on a hinge, either side-hung or top-hung. The frame is built from four pieces of timber: two vertical stiles, a top rail and a bottom rail. The joints are typically morticed and tenoned. For a single-rebated casement, you'll usually work with 44mm or 56mm rebated sections. Double-rebated profiles are used where a second pane or draught seal sits in the frame.
Most DIY and restoration casement projects use softwood, either redwood or whitewood, planed to a rebated profile. If you're painting the frame, the species matters less than getting straight, well-seasoned timber. For external frames left with a clear finish, European oak or accoya are worth the premium.
Sash windows
Box sash windows are more complex. They consist of two sliding sashes that run in a boxed frame, held in balance by weights and cords. The components include the outer linings, inner linings, parting beads, staff beads, sill, head and the sashes themselves (each built from top rail, bottom rail, stiles and glazing bars).
Sash windows are common in Victorian and Edwardian terraces. If you're repairing rather than replacing, you'll often need specific sections: parting bead, staff bead, glazing bead and glazing bars milled to the correct ovolo or lamb's tongue profile. Sizes vary from window to window, so measure the old piece before ordering. Our pine parting bead, for example, is 8mm x 21mm.

Cross-section of a box sash window: where the staff bead, parting bead and glazing bead sit.
Fixed windows
A fixed window has no hinges and does not open. The glass sits in a rebate and is held in place by glazing beads. Fixed frames are the simplest and cheapest timber window to build, which is why they are the usual choice for sheds, workshops, summerhouses and garden rooms. Our flat-pack timber window frame kits are fixed frames, made in our South Wales joinery.
Parts of a Timber Window Frame
Whatever the type, most timber windows share the same basic parts. The outer frame is made up of the head at the top, a jamb on each side and the sill at the bottom. Larger windows are split into sections by a mullion (an upright divider) and a transom (a horizontal divider). Each pane of glass is held in a rebate by glazing beads.

The main parts of a timber casement window.
Rebated Timber for Window Frames Explained
A rebate is the stepped recess machined into the inside edge of a window frame section that the glass or glazing unit sits into. It does two jobs: it locates the glass squarely against the frame, and it gives the glazing bead or putty a shoulder to seal against so weather stays out. Any timber window frame that holds glazing has a rebate somewhere in its profile.
If you are buying rebated timber to build a frame from scratch, the rebate depth needs to suit your glass thickness plus the glazing bead or putty line. Deeper rebates suit sealed double-glazed units; shallow rebates suit single 4mm glass. The rebate is cut into the stiles, top rail and bottom rail so the glass is captured on all four sides once the beads go on.
Buying loose rebated sections and cutting your own joints is fiddly and easy to get out of square. Our flat-pack timber window frame kits take that work off the table: the rebate and glazing beads are already machined and pre-fitted for 4mm glass, and the dovetail keyed mitre joints pull the corners tight and square with nothing more than a hammer. You get the rebated timber result without the router setup.
If you would rather build your own frame, our rebated timber window profile is a 42mm x 42mm Scandinavian redwood section with a 10mm rebate, sized for 4mm glass and sold in lengths from 300mm to 2400mm.

Our 42mm x 42mm window section with its 10mm x 21mm rebate. The glass and glazing bead sit in the step.
Timber Window Frame Sections and Profiles
Timber window sections are sold by their finished (planed) size or their nominal (sawn) size. A nominal 50mm x 75mm piece will finish at approximately 44mm x 69mm after planing. Always confirm whether you're ordering finished or nominal dimensions before you buy.
Common sections for window frame construction:
- Stiles and rails: 44mm x 69mm or 44mm x 95mm finished
- Sash stiles: 44mm x 44mm or 44mm x 57mm finished
- Glazing bars: 32mm x 44mm or custom milled profiles
- Parting bead: around 8mm to 12mm x 20mm (ours is 8mm x 21mm)
- Staff bead: 15mm x 32mm
- Window sill: 44mm x 145mm weathered and throated
If you're working to existing openings in a period property, measure twice before ordering. Openings are rarely perfectly square and the frame needs to be built to suit the actual dimensions, not a standard sheet size.
Timber Window Details: Head, Jamb and Sill
A timber window detail is a cross-section drawing that shows how the frame is built and how it sits in the wall. Architects usually draw three: one through the head, one through a jamb and one through the sill.
- Head detail: shows the top of the frame under the lintel, with a drip or weather moulding so rain runs off rather than into the joint.
- Jamb detail: shows the sides of the frame and how they meet the wall, including the cavity closer, damp proof course and the gap left for fixing and sealant.
- Sill detail: shows the bottom of the frame. The sill is weathered (sloped) to shed water and has a throat or drip groove underneath so water drops clear of the wall below.
For repairs, the sill is usually the first part to rot, because water sits on it. A replacement needs the same slope and drip as the original.

Sill detail: our sash window cill with the sash bottom rail, staff bead and glazing bead.
Standard Timber Window Frame Sizes
The sections above are the individual timber profiles. If you want a complete frame ready to glaze, our flat-pack kits come in a set of standard outer sizes that cover most sheds, workshops and summerhouses. All are supplied unglazed and ready for 4mm glass:
| Frame width | Frame height | Shape |
|---|---|---|
| 1200mm | 1200mm | Square |
| 1100mm | 1200mm | Portrait |
| 1000mm | 1200mm | Portrait |
| 900mm | 1200mm | Portrait |
| 800mm | 1200mm | Portrait |
| 1000mm | 1000mm | Square |
| 900mm | 900mm | Square |
| 800mm | 800mm | Square |
Measure the opening in your building, then pick the frame that fits with a small clearance for packing and sealant. If your opening falls between sizes, size down rather than up. See the full size and price options on the flat-pack window frame kit page.
Best Wood for Timber Window Frames
External joinery takes a beating from rain, UV and temperature changes. The timber needs to be stable, take a finish well and resist rot.
In short: the best timber for windows is European oak or Accoya if you want the longest life, and treated redwood if you are painting the frame and want value.
The best wood for timber window frames depends on the application and finish. For painted external joinery, treated redwood pine is the standard choice in the UK. For natural or stained finishes, European oak is the traditional pick. For high-specification work, accoya offers softwood workability with hardwood-level durability.
At a glance, here's how the main options compare for UK window frames:
| Timber | Durability | Finish | Relative cost | Best for |
|---|---|---|---|---|
| Redwood pine | Good (treated & painted) | Painted | £ | Standard painted joinery |
| European oak | Very good (naturally durable) | Natural / stained | £££ | Unpainted traditional frames |
| Accoya | Excellent (50-yr rot guarantee) | Painted / stained | ££££ | High-spec external joinery |
| MDF | Internal only | Painted | £ | Internal window boards & linings |
Redwood (Scots Pine / Baltic Pine) is the most widely used timber for painted external joinery in the UK. It's stable, widely available and takes paint and primer well. For external use, it should be primed all round before installation and kept well painted. Untreated redwood will deteriorate if left exposed.
European Oak is the traditional choice for unpainted external frames. It's naturally durable, hard-wearing and ages well. It also costs significantly more than softwood and requires pre-drilling for fixings due to its hardness.
Accoya is a modified softwood (usually radiata pine) that has been acetylated to make it dimensionally stable and highly rot-resistant. It's increasingly used in high-specification external joinery and carries a 50-year guarantee against rot above ground. It machines and paints like softwood but performs like hardwood.
For internal window boards and linings, most contractors use MDF or softwood. MDF gives a cleaner painted finish and is less prone to movement, though it won't tolerate moisture in areas where condensation is a concern.
Window frame kits
If you need a complete frame for a shed, outhouse, garden room or agricultural building, a wooden window frame kit is usually the fastest option. Our flat pack timber window frame kit comes pre-cut with a rebate for glazing and pre-fitted glazing beads, and goes together with dovetail keyed mitre joints using just a hammer. Eight standard sizes cover most openings, from 800mm x 800mm up to 1200mm x 1200mm.

An assembled frame from our flat-pack kit.
Need a size that isn't on the list? Our joinery team makes frames to your exact measurements. Call them on 01656 745959 with your opening size.
Sash window parts and glazing bars
Restoring a sash window often means replacing individual components rather than the whole frame. The most commonly needed parts are glazing bars (which hold the individual panes), beads (which retain the glass in the rebate) and sash horns (the decorative extension at the bottom corners of the upper sash).
Glazing bars are milled to a specific profile: ovolo is the most common in Victorian properties, with a rounded edge facing the room. Lamb's tongue is found in earlier Georgian windows and has a more pronounced S-curve. If you're replacing a single bar, take a cross-section to match the profile accurately.
For individual sash components, browse our sash window timber parts, including glazing bars, staff beads and parting beads.
Browse our full range of window and door timber sections, including glazing bars, beads, sash components and frame sections.
Installation tips
A few practical points before you start:
- Prime all end grain and all faces before installation, not just the visible surfaces. End grain is where moisture gets in first.
- Leave a 3mm gap on each side of the frame in the opening for adjustment and allow for mortar packing.
- Use stainless steel or galvanised fixings. Bright steel will rust behind the paint and cause staining and frame failure within a few years.
- Silicone the external perimeter seal after painting, not before. Paint won't bond to cured silicone.
- In exposed locations, consider a drip groove on the underside of the sill to prevent water tracking back under the frame.
For profiles, beadings and mouldings to finish the frame internally, take a look at our beadings and mouldings range.
